CW3xx系列LVCMOS時鐘振蕩器Connor-Winfield?

發布時間：2024-03-22 10:40:30 瀏覽：513

Connor-Winfield 推出的時鐘振蕩器，以其卓越的穩定性和可靠性，成為以太網、光纖通道、SONET/SDH、T1/E1、T3/E3 線卡以及服務器和存儲平臺的理想選擇。

其中，Connor-Winfield CW3xx系列以其小巧的3.2x2.5mm尺寸、LCMOS設計以及表面貼裝特性，成為追求低抖動和高度頻率穩定性的應用的優選。其RoHS標準的表面貼裝封裝，不僅滿足了高密度安裝的需求，也更適合大批量生產，極大提升了生產效率。

CW3xx系列LVCMOS時鐘振蕩器Connor-Winfield

這款產品的亮點如下：

供電電壓：1.8V、2.5V、2.8V或3.3V

頻率公差：±25ppm、±50ppm或±100ppm

工作溫度范圍：-10℃至70℃或-40℃至85℃

采用LVCMOS輸出邏輯，保證信號的清晰和準確。

三態Pad使能/使能功能，提供更大的操作靈活性。

低抖動特性，抖動值小于1ps RMS

采用陶瓷表面貼裝封裝

提供膠帶和卷軸包裝

符合RoHS標準，無鉛設計，環保且安全。

純頻譜系列頻率范圍：1.0MHz至160MHz

穩定性：25ppm

產品型號：

Part Number	Product Type	Logic Family	Package	Frequency Stability	Frequency Tolerance	Frequency Calibration	Supply Voltage	Frequency Range	Temperature Range	Pull Range	Keyword
CW31 Series RoHS	Clock	LVCMOS	SM 3.2x2.5mm	N/A	+/-25ppm to +/-100ppm	N/A	1.8 to 3.3 Vdc	1.0 MHz to 160 MHz	-10 to 70c	N/A	Low Cost
CW32 Series RoHS	Clock	LVCMOS	SM 3.2x2.5mm	N/A	+/-25ppm to +/-100ppm	N/A	1.8 to 3.3 Vdc	1.0 MHz to 160 MHz	-10 to 70c	N/A	Low Cost
CW33 Series RoHS	Clock	LVCMOS	SM 3.2x2.5mm	N/A	+/-25ppm to +/-100ppm	N/A	1.8 to 3.3 Vdc	1.0 MHz to 160 MHz	-10 to 70c	N/A	Low Cost
CW34 Series RoHS	Clock	LVCMOS	SM 3.2x2.5mm	N/A	+/-25ppm to +/-100ppm	N/A	1.8 to 3.3 Vdc	1.0 MHz to 160 MHz	-10 to 70c	N/A	Low Cost
CW35 Series RoHS	Clock	LVCMOS	SM 3.2x2.5mm	N/A	+/-25ppm to +/-100ppm	N/A	1.8 to 3.3 Vdc	1.0 MHz to 160 MHz	-40 to 85c	N/A	Low Cost
CW36 Series RoHS	Clock	LVCMOS	SM 3.2x2.5mm	N/A	+/-25ppm to +/-100ppm	N/A	1.8 to 3.3 Vdc	1.0 MHz to 160 MHz	-40 to 85c	N/A	Low Cost
CW37 Series RoHS	Clock	LVCMOS	SM 3.2x2.5mm	N/A	+/-25ppm to +/-100ppm	N/A	1.8 to 3.3 Vdc	1.0 MHz to 160 MHz	-40 to 85c	N/A	Low Cost
CW38 Series RoHS	Clock	LVCMOS	SM 3.2x2.5mm	N/A	+/-25ppm to +/-100ppm	N/A	1.8 to 3.3 Vdc	1.0 MHz to 160 MHz	-40 to 85c	N/A	Low Cost

供應Connor-Winfield壓控溫度補償晶體振蕩器VCTCXO

供應Connor-Winfield壓控晶體振蕩器VCXO

供應Connor-Winfield恒溫晶體振蕩器OCXO

供應Connor-Winfield壓控恒溫晶體振蕩器VCOCXO

供應Connor-Winfield時鐘同步發生器

供應Connor-Winfield頻率轉換模塊

更多Connor-Winfield晶振產品可咨詢立維創展。
