LFE2-6E-5T144C現場可編程門陣列FPGA
發布于：2024-07-29 16:25:00
品牌名稱：Lattice
重要參數：
型號：ECP2M系列
I/O：90~583個
LUTs：6K~95K
電源：1.2V
| Device | ECP2-6 | ECP2-12 | ECP2-20 | ECP2-35 | ECP2-50 | ECP2-70 |
| LUTs(K) | 6 | 12 | 21 | 32 | 48 | 68 |
| Distributed RAM (Kbits) | 12 | 24 | 42 | 64 | 96 | 136 |
| EBA SRAM (Kbits) | 55 | 221 | 276 | 332 | 387 | 1032 |
| EBR SRAM Blocks | 3 | 12 | 15 | 18 | 21 | 60 |
| sysDSP Blocks | 3 | 6 | 7 | 8 | 18 | 22 |
| 18x18 Multipliers | 12 | 24 | 28 | 32 | 72 | 88 |
| GPLL+SPLL+DLL | 2+0+2 | 2+0+2 | 2+0+2 | 2+0+2 | 2+2+2 | 2+4+2 |
| Maximum Avallable VO | 190 | 297 | 402 | 450 | 500 | 583 |
| Packages and VO Combinations |
| 144-pin TQFP(20x20 mm) | 90 | 93 |
|
|
|
|
| 208-pin PQFP (28 ×28 mm) |
| 131 | 131 |
|
|
|
| 256-ball fpBGA(17x17mm) | 190 | 193 | 193 |
|
|
|
| 484-ball fpBGA (23 x23 mm) |
| 297 | 331 | 331 | 339 |
|
| 672-ball fpBGA (27 x27 mm) |
|
| 402 | 450 | 500 | 500 |
| 900-ball fpBGA (31x31 mm) |
|
|
|
|
| 583 |
|
| Device | ECP2M20 | ECP2M35 | ECP2M50 | ECP2M70 | ECP2M100 |
| LUTs(K) | 19 | 34 | 48 | 67 | 95 |
| sysMEM Blocks (18kb) | 66 | 114 | 225 | 246 | 288 |
| Embedded Memory (Kbits) | 1217 | 2101 | 4147 | 4534 | 5308 |
| Distributed Memory (Kbits) | 41 | 71 | 101 | 145 | 202 |
| sysDSP Blocks | 6 | 8 | 22 | 24 | 42 |
| 18x18 Multipliers | 24 | 32 | 88 | 96 | 168 |
| GPLL+SPLL+DLL | 2+6+2 | 2+6+2 | 2+6+2 | 2+6+2 | 2+6+2 |
| Maximum Available I/O | 304 | 410 | 410 | 436 | 520 |
| Packages andSERDES /VO Combinations |
| 256-ball fpBGA(17x17 mm) | 4/2040 | 4/2040 |
|
|
|
| 484-ball fpBGA(23x23 mm) | 4/304 | 4/303 | 4/270 |
|
|
| 672-ball fpBGA (27x27 mm) |
| 4/410 | 8/372 |
|
|
| 900-ball fpBGA (31x31 mm) |
|
| 8/410 | 16/416 | 16/416 |
| 1152-ball fpBGA(35x35 mm) |
|
|
| 16/436 | 16/520 |
型號：
| LFE2-6E-5T144C | LFE2-35E-5F484C | LFE2-20E-5Q208 | LFE2-6E-5TN144C | LFE2-35E-5FN484C | LFE2-20E-5QN208I | LFE2-6SE-5T144C |
| LFE2-6E-6T144C | _FE2-35E-6F484C | LFE2-20E-6Q208 | LFE2-6E-6TN144C | LFE2-35E-6FN484C | LFE2-20E-6QN208I | LFE2-6SE-6T144C |
| LFE2-6E-7T144C | LFE2-35E-7F484C | LFE2-20E-5F256 | LFE2-6E-7TN144C | LFE2-35E-7FN484C | LFE2-20E-5FN256I | LFE2-6SE-7T144C |
| LFE2-6E-5F256C | LFE2-35E-5F672C | LFE2-20E-6F256I | LFE2-6E-5FN256C | LFE2-35E-5FN672C | LFE2-20E-6FN256I | LFE2-6SE-5F256C |
| LFE2-6E-6F256C | LFE2-35E-6F672C | LFE2-20E-5F484I | LFE2-6E-6FN256C | LFE2-35E-6FN672C | LFE2-20E-5FN4841 | LFE2-6SE-6F256C |
| LFE2-6E-7F256C | _FE2-35E-7F672C | LFE2-20E-6F484I | LFE2-6E-7FN256C | LFE2-35E-7FN672C | LFE2-20E-6FN4841 | LFE2-6SE-7F256C |
| LFE2-12E-5T144C | __FE2-50E-5F484C | LFE2-20E-5F672I | LFE2-12E-5TN144C | LFE2-50E-5FN484C | LFE2-20E-5FN672I | LFE2-12SE-5T144C |
| LFE2-12E-6T144C | LFE2-50E-6F484C | LFE2-20E-6F672 | LFE2-12E-6TN144C | LFE2-50E-6FN484C | LFE2-20E-6FN672I | LFE2-12SE-6T144C |
| LFE2-12E-7T144C | LFE2-50E-7F484C | LFE2-35E-5F484I | LFE2-12E-7TN144C | LFE2-50E-7FN484C | LFE2-35E-5FN4841 | LFE2-12SE-7T144C |
| LFE2-12E-50208C | LFE2-50E-5F672C | LFE2-35E-6F484I | LFE2-12E-5QN208C | LFE2-50E-5FN672C | LFE2-35E-6FN484I | LFE2-12SE-5Q208C |
| LFE2-12E-6Q208C | LFE2-50E-6F672C | LFE2-35E-5F672I | LFE2-12E-6QN208C | LFE2-50E-6FN672C | LFE2-35E-5FN672I | LFE2-12SE-6Q208C |
| LFE2-12E-7Q208C | LFE2-50E-7F672C | LFE2-35E-6F672I | LFE2-12E-7QN208C | LFE2-50E-7FN672C | LFE2-35E-6FN672I | LFE2-12SE-7Q208C |
| LFE2-12E-5F256C | LFE2-70E-5F672C | LFE2-50E-5F484I | LFE2-12E-5FN256C | LFE2-70E-5FN672C | LFE2-50E-5FN484I | LFE2-12SE-5F256C |
| LFE2-12E-6F256C | FE2-70E-6F672C | LFE2-50E-6F484 | LFE2-12E-6FN256C | LFE2-70E-6FN672C | LFE2-50E-6FN484I | LFE2-12SE-6F256C |
| LFE2-12E-7F256C | LFE2-70E-7F672C | LFE2-50E-5F672I | LFE2-12E-7FN256C | LFE2-70E-7FN672C | LFE2-50E-5FN672I | LFE2-12SE-7F256C |
| LFE2-12E-5F484C | LFE2-70E-5F900C | LFE2-50E-6F672I | LFE2-12E-5FN484C | LFE2-70E-5FN900C | LFE2-50E-6FN672I | LFE2-12SE-5F484C |
| LFE2-12E-6F484C | FF2-70F-6F9000 | LFE2-70E-5F672I | LFE2-12E-6FN484C | LFE2-70E-6FN900C | LFE2-70E-5FN672I | LFE2-12SE-6F484C |
| LFE2-12E-7F484C | LFE2-70E-7F900C | LFE2-70E-6F672I | LFE2-12E-7FN484C | LFE2-70E-7FN900C | LFE2-70E-6FN672I | LFE2-12SE-7F484C |
| LFE2-20E-5Q208C | LFE2-6E-5T144 | LFE2-70E-5F900 | LFE2-20E-5QN208C | LFE2-6E-5TN144I | LFE2-70E-5FN9001 | LFE2-20SE-5Q208C |
| LFE2-20E-6Q208C | LFE2-6E-6T1441 | LFE2-70E-6F900I | LFE2-20E-6QN208C | LFE2-6E-6TN144I | LFE2-70E-6FN9001 | LFE2-20SE-6Q208C |
| LFE2-20E-70208C | FF2-6E-5F256 | LFE2-208E-502081 | LFE2-20E-7QN208C | LFE2-6E-5FN256I | LFE2M100E-5F11521 | LFE2-20SE-7Q208C |
| LFE2-20E-5F256C | FE2-6E-6F256 | LFE2-20SE-60208 | LFE2-20E-5FN256C | LFE2-6E-6FN256I | LFE2M100E-6F1152 | LFE2-20SE-5F256C |
| LFE2-20E-6F256C | LFE2-12E-5T144I | LFE2-208E-5F256 | LFE2-20E-6FN256C | LFE2-12E-5TN144 | LFE2M100E-5F900 | LFE2-20SE-6F256C |
| LFE2-20E-7F256C | LFE2-12E-6T144I | L=E2-20SE-6F256I | LFE2-20E-7FN256C | LFE2-12E-6TN144 | LFE2M100E-6F9001 | LFE2-20SE-7F256C |
| LFE2-20E-5F484C | IFF2-12F-50208 | LFE2-208E-5F484 | LFE2-20E-5FN484C | LFE2-12E-5QN208I | LFE2M208E-5FN484 | LFE2-20SE-5F484C |
| LFE2-20E-6F484C | LFE2-12E-6Q208 | L=E2-20SE-6F484I | LFE2-20E-6FN484C | LFE2-12E-6QN208I | LFE2M208E-6FN484 | LFE2-20SE-6F484C |
| LFE2-20E-7F484C | LFE2-12E-5F256I | LFE2-208E-5F672 | LFE2-20E-7FN484C | LFE2-12E-5FN256 | LFE2M208E-5FN256 | LFE2-20SE-7F484C |
| LFE2-20E-5F672C | LFE2-12E-6F256 | LFE2-20SE-6F6721 | LFE2-20E-5FN672C | LFE2-12E-6FN256 | LFE2M20SE-6FN256 | LFE2-20SE-5F672C |
| LFE2-20E-6F672C | LFE2-12E-5F484I | LFE2-35SE-5F484I | LFE2-20E-6FN672C | LFE2-12E-5FN4841 | LFE2M35SE-5FN672 | LFE2-20SE-6F672C |
| LFE2-20E-7F672C | FF2-12E-6F484 | LFE2-35SE-6F484 | LFE2-20E-7FN672C | LFE2-12E-6FN484I | LFE2M35SE-6FN672I | LFE2-20SE-7F672C |
| LFE2-35SE-5F484C | LFE2-6SE-5TN144C | LFE2-35SE-5F672 | LFE2-35SE-5FN484C | LFE2M20日-5F484C | LFE2M35SE-5FN484 | LFE2M208E-5F484I |
| LFE2-35SE-6F484C | LFE2-6SE-6TN144C | LFE2-358E-6F672 | LFE2-35SE-6FN484C | LFE2M20日-6F484C | LFE2M35SE-6FN4841 | LFE2M208E-6F484I |
| LFE2-35SE-7F484C | LFE2-6SE-7TN144C | LFE2-508E-5F484 | LFE2-35SE-7FN484C | LFE2M20日-7F4840 | LFE2M35SE-5FN256 | LFE2M208E-5F256 |
| L=E2-35SE-5F672C | LFE2-6SE-5FN256C | LFE2-50SE-6F4841 | LFE2-35SE-5FN672C | LFE2M20日-5F256C | LFE2M35SE-6FN256I | LFE2M20SE-6F256 |
| L=E2-35SE-6F672C | LFE2-6SE-6FN256C | LFE2-508E-5F672 | LFE2-35SE-6FN672C | LFE2M20日-6F256C | LFE2M508E-5FN900 | LFE2M358E-5F672I |
| LFE2-35SE-7F6720 | LFE2-6SE-7FN256C | LFE2-50SE-6F6721 | LFE2-35SE-7FN672C | LFE2M201-7F2560 | LFE2M508E-6FN900 | LFE2M358E-6F672I |
| LFE2-50SE-5F4840 | LFE2-12SE-5TN144C | LFE2-70SE-5F672 | LFE2-50SE-5FN484C | LFE2M35E-5F672C | LFE2M50SE-5FN672I | LFE2M358E-5F484I |
| LFE2-50SE-6F484C | LFE2-12SE-6TN144C | LFE2-70SE-6F672 | LFE2-50SE-6FN484C | LFE2M35E-6F672C | LFE2M508E-6FN672 | LFE2M358E-6F484I |
| LFE2-50SE-7F484C | LFE2-12SE-7TN144C | LFE2-70SE-5F900 | LFE2-50SE-7FN484C | LFE2M35E-7F672C | LFE2M508E-5FN484 | LFE2M358E-5F256I |
| LFE2-50SE-5F6720 | LFE2-12SE-5QN208C | LFE2-70SE-6F900 | LFE2-50SE-5FN672C | LFE2M35E-5F484C | LFE2M50SE-6FN484 | LFE2M358E-6F256I |
| LFE2-50SE-6F6720 | LFE2-12SE-6QN208C | LFE2M20E-5F484 | LFE2-50SE-6FN672C | LFE2M35E-6F484C | LFE2M70SE-5FN1152 | LFE2M508E-5F900I |
| LFE2-50SE-7F6720 | LFE2-12SE-7QN208C | LFE2M20E-6F484 | LFE2-50SE-7FN672C | LFE2M35E-7F484C | LFE2M70SE-6FN1152 | LFE2M508E-6F900I |
| LFE2-70SE-5F672C | LFE2-12SE-5FN256C | LFE2M20E-5F256I | LFE2-70SE-5FN672C | LFE2M35E-5F2560 | LFE2M708E-5FN900 | LFE2M508E-5F672I |
| LFE2-70SE-6F6720 | LFE2-12SE-6FN256C | LFE2M20E-6F256I | LFE2-70SE-6FN672C | LFE2M35E-6F2560 | LFE2M708E-6FN900 | LFE2M508E-6F672I |
| LFE2-70SE-7F6720 | LFE2-12SE-7FN256C | LFE2M35E-5F672 | LFE2-70SE-7FN672C | LFE2M35E-7F256C | LFE2M100SE-5FN1152I | LFE2M508E-5F484I |
| LFE2-70SE-5F9000 | LFE2-12SE-5FN484C | LFE2M35E-6F6721 | LFE2-70SE-5FN900C | LFE2M50E-5F9000 | LFE2M100SE-6FN1152 | LFE2M50SE-6F484 |
| LFE2-70SE-6F9000 | LFE2-12SE-6FN484C | LFE2M35E-5F484 | LFE2-70SE-6FN900C | LFE2M50E-6F900C | LFE2M100SE-5FN900I | LFE2M708E-5F1152 |
| LFE2-70SE-7F9000 | LFE2-12SE-7FN484C | LFE2M35E-6F484 | LFE2-70SE-7FN900C | LFE2M50E-7F9000 | LFE2M100SE-6FN900 | LFE2M708E-6F1152 |
| LFE2-6SE5T1441 | LFE2-20SE-5QN208C | LFE2M35E-5F256I | LFE2-6SE-5TN144 | LFE2M50E-5F672C | LFE2M708E-5F11520 | LFE2M708E-5F900I |
| LFE2-68E-6T1441 | LFE2-20SE-6QN208C | LFE2M35E-6F256 | LFE2-6SE-6TN144 | LFE2M50E-6F672C | LFE2M708E-6F11520 | LFE2M70SE-6F900 |
| LFE2-68E-5F256I | LFE2-20SE-7QN208C | LFE2M50E-5F900 | LFE2-6SE-5FN256 | LFE2M50E-7F672C | LFE2M70SE-7F11520 | LFE2M1003E-5F11521 |
| LFE2-68E-6F256I | LFE2-20SE-5FN256C | LFE2M50E-6F900 | LFE2-6SE-6FN256 | LFE2M50E-5F484C | LFE2M70SE-5F9000 | LFE2M100SE-6F11521 |
| LFE2-12SE-5T1441 | LFE2-20SE-6FN256C | LFE2M50E-5F6721 | LFE2-12SE-5TN144 | LFE2M50E-6F484C | LFE2M70SE-6F900C | LFE2M1003E-5F900 |
| LFE2-12SE-6T1441 | LFE2-20SE-7FN256C | LFE2M50E-6F672 | LFE2-12SE-6TN144 | LFE2M50E-7F484C | LFE2M70SE-7F900C | LFE2M100SE-6F900 |
| LFE2-12SE-50208 | LFE2-20SE-5FN484C | LFE2M50E-5F4841 | LFE2-12SE-5QN208 | LFE2M70E-5F1152C | LFE2M100SE-5F11520 | LFE2M100SE-5FN1152C |
| LFE2-12SE-60208 | LFE2-20SE-6FN484C | LFE2M50E-6F484 | LFE2-12SE-6QN208 | LFE2M70E-6F1152C | LFE2M100SE-6F1152C | LFE2M100SE-6FN1152C |
| LFE2-128E-5F256I | LFE2-20SE-7FN484C | LFE2M70E-5F1152 | LFE2-12SE-5FN256 | LFE2M70E-7F1152C | LFE2M100SE-7F1152C | LFE2M100SE-7FN1152C |
| LFE2-12SE-6F256I | LFE2-20SE-5FN672C | LFE2M70E-6F11521 | LFE2-12SE-6FN256 | LFE2M70E-5F9000 | LFE2M100SE-5F9000 | LFE2M100SE-5FN900C |
| LFE2-12SE-5F4841 | LFE2-20SE-6FN672C | LFE2M70E-5F900I | LFE2-12SE-5FN484 | LFE2M70E-6F900C | LFE2M100SE-6F9000 | LFE2M100SE-6FN900C |
| LFE2-12SE-6F4841 | LFE2-20SE-7FN672C | LFE2M70E-6F900I | LFE2-128E-6FN484 | LFE2M70E-7F900C | LFE2M100SE-7F9000 | LFE2M100SE-7FN900C |
