產品概述
型號范圍：1N6036A至1N6072A
封裝：軸向封裝，適用于通孔安裝
峰值脈沖功率：1500W，具有極快的響應時間
應用：主要用于保護電子設備免受感性切換環境、射頻感應效應或二次雷擊效應(如IEC61000-4-5標準中的較低浪涌水平)的影響，也成功用于保護航空電子和電氣系統。
特點
雙向TVS系列：適用于雙向電壓保護
高脈沖功率：在10/1000微秒下可抑制高達1500W的瞬態
快速響應：在不到100皮秒內鉗制瞬態
工作電壓范圍：5.5V至185V
封裝：密封的DO-13金屬封裝
軍事認證：提供JAN, JANTX, JANTXV等級，符合MIL-PRF-19500/507標準
RoHS合規：提供符合RoHS標準的版本(僅限商業級)
應用
開關瞬態和射頻感應保護
ESD和EFT保護：符合IEC 61000-4-2和IEC 61000-4-4標準
二次雷擊保護：符合IEC61000-4-5標準，不同阻抗源下的不同等級保護
最大額定值
結溫和存儲溫度：-55°C至+175°C
峰值脈沖功率：1500W(在+25°C下)
額定平均功率耗散：1W(在+125°C下)
焊接溫度：260°C
電氣特性
工作電壓(VWM)：確保非導通狀態的反向電壓
擊穿電壓(V(BR))：設備在25°C時展現的擊穿電壓
最大鉗制電壓(VC)：在一毫秒時間間隔內，TVS承受峰值脈沖電流時的最大峰值電壓
峰值脈沖電流(IPP)：脈沖期間的峰值電流
備用電流(ID)：在工作電壓(VWM)下的電流
封裝尺寸
DO-13 (DO-202AA)：密封金屬和玻璃封裝，所有外部金屬表面都鍍有錫鉛，符合MIL-STD-750方法2026的可焊性。
型號參數：
JEDEC
Type
No | Rated
Standoff
Voltage
VwM | Breakdown
Voltage
VBR] | Maximum
Clamping
Voltage
Vcat Ipp | Maximum
Standby
Current
lo at VwM | Maximum
Peak Pulse
Current
lpp
(SeeFigure
3-2) | Maximum
Temperature
Coefficientof
V(aR |
| V(aRjmin | VBRjmax | at Ika |
| V | V | V | mA | V | pA | A | Cy(BR
%/°C |
| 1N6036 | 5.5 | 6.75 | 8.25 | 10 | 11.7 | 1000 | 128 | 0.061 |
| *1N6036A | 6.0 | 7.13 | 7.88 | 10 | 113 | 1000 | 132 | 0.061 |
| 1N6037 | 6.5 | 7.38 | 9.02 | 10 | 12.5 | 500 | 120 | 0.065 |
| *1N6037A | 7.0 | 7.79 | 8.61 | 10 | 12.1 | 500 | 124 | 0.065 |
| 1N6038 | 7.0 | 8.19 | 10.00 | 10 | 13.8 | 200 | 109 | 0.068 |
| *1N6038A | 7.5 | 8.65 | 9.55 | 10 | 13.4 | 200 | 112 | 0.068 |
| 1N6039 | 8.0 | 9.0 | 11.0 | 1 | 15.0 | 50 | 100 | 0.073 |
| *1N6039A | 8.5 | 9.5 | 10.5 | 1 | 14.5 | 50 | 103 | 0.073 |
| 1N6040 | 8.5 | 9.9 | 12.1 | 1 | 16.2 | 10 | 93 | 0.075 |
| *1N6040A | 9.0 | 10.5 | 11.6 | 1 | 15.6 | 10 | 96 | 0.075 |
| 1N6041 | 9.0 | 10.8 | 13.2 | 1 | 173 | 5 | 87 | 0.078 |
| *1N6041A | 10.0 | 11.4 | 12.6 | 1 | 16.7 | 5 | 90 | 0.078 |
| 1N6042 | 10.0 | 11.7 | 14.3 | 1 | 19.0 | 5 | 79 | 0.081 |
| *1N6042A | 11.0 | 12.4 | 13.7 | 1 | 18.2 | 5 | 82 | 0.081 |
| 1N6043 | 11.0 | 13.5 | 16.5 | 1 | 22.0 | 5 | 68 | 0.084 |
| *1N6043A | 12.0 | 14.3 | 15.8 | 1 | 21.2 | 5 | 71 | 0.084 |
| 1N6044 | 12.0 | 14.4 | 17.5 | 1 | 23.5 | 5 | 64 | 0.086 |
| *1N6044A | 13.0 | 15.2 | 16.8 | 1 | 22.5 | 5 | 67 | 0.086 |
| 1N6045 | 14.0 | 16.2 | 19.8 | 1 | 26.5 | 5 | 56.5 | 0.088 |
| *1N6045A | 15.0 | 17.1 | 18.9 | 1 | 25.2 | 5 | 59.5 | 0.088 |
| 1N6046 | 16.0 | 18.0 | 22.0 | 1 | 29.1 | 5 | 51.5 | 0.090 |
| *1N6046A | 17.0 | 19.0 | 21.0 | 1 | 27.7 | 5 | 54 | 0.090 |
| 1N6047 | 17.0 | 19.8 | 24.2 | 1 | 31.9 | 5 | 47 | 0.092 |
| *1N6047A | 18.0 | 20.9 | 23.1 | 1 | 30.6 | 5 |
| 0.092 |
1N6048
*1N6048A
1N6049
1N6049A | 19.0
20.0
21.0
22.0 | 21.6
22.8
24.3
25.7 | 26.4
25.2
29.7
28.4 | 1
1
1
1 | 34.7
33.2
39.1
37.5 | 5
5
5
5 | 43
45
38.5
40 | 0.094
0.094
0.095
0.096 |
| 1N6050 | 24.0 | 27.0 | 33.0 | 1 | 43.5 | 5 | 34.5 | 0.097 |
| *1N6050A | 25.0 | 28.5 | 31.5 | 1 | 41.4 | 5 | 36 | 0.097 |
| 1N6051 | 26.0 | 29.7 | 36.3 | 1 | 47 | 5 | 31.5 | 0.098 |
| *1N6051A | 28.0 | 31.4 | 34.7 | 1 | 45.7 | 5 | 33 | 0.098 |
| 1N6052 | 29.0 | 32.4 | 39.6 | 1 | 52.0 | 5 | 29 | 0.099 |
| *1N6052A | 30.0 | 34.2 | 37.8 | 1 | 49.9 | 5 | 30 | 0.099 |
| 1N6053 | 31.0 | 35.1 | 42.9 | 1 | 56.4 | 5 | 26.5 | 0.100 |
| *1N6053A | 33.0 | 37.1 | 41.0 | 1 | 53.9 | 5 | 28 | 0.100 |
| 1N6054 | 34.0 | 38.7 | 47.3 | 1 | 61.9 | 5 | 24 | 0.101 |
| *1N6054A | 36.0 | 40.9 | 45.2 | 1 | 593 | 5 | 25.3 | 0.101 |
| 1N6055 | 38.0 | 42.3 | 51.7 | 1 | 67.8 | 5 | 22.2 | 0.101 |
| *1N6055A | 40.0 | 44.7 | 49.4 | 1 | 64.8 | 5 | 23.2 | 0.101 |
| 1N6056 | 41.0 | 45.9 | 56.1 | 1 | 73.5 | 5 | 20.4 | 0.102 |
| *1N6056A | 43.0 | 48.5 | 53.6 | 1 | 70.1 | 5 | 21.4 | 0.102 |
| 1N6057 | 45.0 | 50.4 | 61.6 | 1 | 80.5 | 5 | 18.6 | 0.103 |
| *1N6057A | 47.0 | 53.2 | 58.8 | 1 | 77.0 | 5 | 19.5 | 0.103 |
| 1N6058 | 48.0 | 55.8 | 68.2 | 1 | 89.0 | 5 | 16.9 | 0.104 |
| *1N6058A | 53.0 | 58.9 | 65.1 | 1 | 85.0 | 5 | 17.7 | 0.104 |
| 1N6059 | 55.0 | 61.2 | 74.8 | 1 | 98.0 | 5 | 15.3 | 0.104 |
| *1N6059A | 58.0 | 64.6 | 71.4 | 1 | 92.0 | 5 | 16.3 | 0.104 |
| 1N6060 | 60.0 | 67.5 | 82.5 | 1 | 108.0 | 5 | 13.9 | 0.105 |
| *1N6060A | 64.0 | 71.3 | 78.8 | 1 | 103.0 | 5 | 14.6 | 0.105 |
| 1N6061 | 66.0 | 73.8 | 90.2 | 1 | 118.0 | 5 | 12.7 | 0.105 |
| *1N6061A | 70.0 | 77.9 | 86.1 | 1 | 113.0 | 5 | 13.3 | 0.105 |
| 1N6062 | 73.0 | 81.9 | 100.0 | 1 | 131.0 | 5 | 11.4 | 0.106 |
| *1N6062A | 75.0 | 86.5 | 95.5 | 1 | 125.0 | 5 | 12.0 | 0.106 |
| 1N6063 | 81.0 | 90.0 | 110.0 | 1 | 144.0 | 5 | 10.4 | 0.106 |
| 1N6063A | 82.0 | 95.0 | 105.0 | 1 | 137.0 | 5 | 11.0 | 0.106 |
| 1N6064 | 90.0 | 99.0 | 121.0 | 1 | 158.0 | 5 | 9.5 | 0.107 |
| *1N6064A | 94.0 | 105.0 | 116.0 | 1 | 152.0 | 5 | 9.9 | 0.107 |
| 1N6065 | 95.0 | 108.0 | 132.0 | 1 | 176.0 | 5 | 8.5 | 0.107 |
| *1N6065A | 100.0 | 114.0 | 126.0 | 1 | 168.0 | 5 | 8.9 | 0.107 |
| 1N6066 | 105.0 | 117.0 | 143.0 | 1 | 191.0 | 5 | 7.8 | 0.107 |
| *1N6066A | 110.0 | 124.0 | 137.0 | 1 | 182.0 | 5 | 8.2 | 0.107 |
| 1N6067 | 121.0 | 135.0 | 165.0 | 1 | 223.0 | 5 | 6.7 | 0.108 |
| *1N6067A | 128.0 | 143.0 | 158.0 | 1 | 213.0 | 5 | 7.0 | 0.108 |
| 1N6068 | 137.0 | 153.0 | 187.0 | 1 | 258.0 | 5 | 5.8 | 0.108 |
| *1N6068A | 145.0 | 162.0 | 179.0 | 1 | 245.0 | 5 | 6.1 | 0.108 |
| 1N6069 | 145.0 | 162.0 | 198.0 | 1 | 274.0 | 5 | 5.5 | 0.108 |
| *1N6069A | 150.0 | 171.0 | 189.0 | 1 | 261.0 | 5 | 5.7 | 0.108 |
| 1N6070 | 155.0 | 171.0 | 210.0 | 1 | 292.0 | 5 | 5.1 | 0.108 |
| *1N6070A | 160.0 | 181.0 | 200.0 | 1 | 278.0 | 5 | 5.4 | 0.108 |
| 1N6071 | 165.0 | 180.0 | 220.0 | 1 | 308.0 | 5 | 4.9 | 0.108 |
| *1N6071A | 170.0 | 190.0 | 210.0 | 1 | 294.0 | 5 | 5.1 | 0.108 |
1N6072
*1N6072A | 175.0
185.0 | 198.0
209.0 | 242.0
231.0 | 1
1 | 344.0
328.0 | 5
5 | 4.3
4.6 | 0.108
0.108 |
